The Maserati GranSport arrived in 2004 as the focused development of the 4200 Coupé. It retained Giugiaro’s four-seat shape and Ferrari-built dry-sump V8, but added more power, a lower chassis, quicker Cambiocorsa software, revised aerodynamics and a cabin designed to feel more sporting.
Quick answer: The GranSport Coupé was built from 2004 to 2007 and the Spyder from 2005 to 2007. Its 4,244cc naturally aspirated V8 produces 400hp and drives through a six-speed automated-manual transaxle. Maserati records 2,640 coupés and 473 Spyders. Inspect clutch wear, hydraulic shift operation, service history, suspension, Skyhook dampers, corrosion, sticky interior finishes and model-specific carbon trim.
Featured image: Blue Maserati GranSport front three-quarter view. Photograph by urbanmixer, CC BY-SA 2.0, via Wikimedia Commons; locally hosted.
How the GranSport changed the 4200 Coupé
The earlier Coupé had already replaced the 3200’s twin-turbo engine with a 4.2-litre naturally aspirated V8 and removed the boomerang lamps. GranSport development concentrated on response. Revised intake and exhaust tuning raised output to 400hp, while gearbox software reduced shift times and the suspension sat lower.
A deeper front bumper, side skirts, small boot spoiler and aerodynamically developed underbody distinguished the exterior. Nineteen-inch Trofeo-style wheels filled the arches. Inside, carbon-weave trim, figure-hugging seats and a different steering wheel moved the atmosphere away from pure grand touring.
V8, Cambiocorsa and specifications
The 4,244cc dry-sump V8 belongs to the F136 family and develops 400hp. It is mounted behind the front axle line and linked by a torque tube to a rear-mounted six-speed transaxle. Cambiocorsa uses an automated clutch and hydraulic actuators, controlled by paddles rather than a conventional clutch pedal.
| Item | GranSport specification |
|---|---|
| Engine | 4,244cc naturally aspirated V8 |
| Output | 400hp |
| Transmission | Six-speed Cambiocorsa automated manual |
| Coupé production | 2,640 |
| Spyder production | 473 |
It should not creep or shift like a torque-converter automatic. Smooth results require lifting slightly during low-speed changes; violent engagement, slow selection or persistent warning messages point to wear or hydraulic faults.
Love cars you don’t see every day?
Get forgotten cars, surprising motoring stories and the most interesting finds from Unusual Cars by email.
Free to join. No spam. Unsubscribe whenever you like. See our privacy policy.
Spyder and MC Victory
The GranSport Spyder combined the uprated mechanical package with the shorter open body. Roof operation, hydraulic components, drains, seals and structural condition all need checking. Water under carpets can affect electronics and trim even when the hood appears sound.
The limited MC Victory celebrated Maserati’s 2005 FIA GT manufacturers’ title. It added more conspicuous carbon-fibre components, racing-influenced seats and blue-accented details. Verify identity and equipment through the factory build record: normal GranSports are easily fitted with similar wheels, spoilers or cabin trim.
Clutch, gearbox and drivetrain checks
Ask for a current diagnostic clutch-wear reading, but interpret it with service history and driving behaviour rather than as an absolute promise of remaining life. Check the clutch position sensor, hydraulic pump, accumulator, actuator and fluid. The car should select first and reverse promptly, pull away without shudder and shift consistently when hot.
Inspect engine and gearbox mounts, torque tube, driveshafts and differential for leaks, vibration or noise. The dry-sump V8 needs correct oil level and annual servicing. Listen for variator or chain-related noise, examine cooling and oil systems, and confirm that exhaust valves and catalysts operate without warning lights.
Chassis, brakes and bodywork
Skyhook dampers were part of the GranSport package in many markets and should respond correctly without leakage or suspension warnings. Check wishbone bushes, ball joints, anti-roll-bar links, wheel bearings and alignment. Nineteen-inch wheels are easily damaged and old tyres can make the chassis feel nervous.
Inspect sills, subframes, brake and fuel lines, floor seams and suspension mounts for corrosion, especially on UK cars used through winter. Front bumpers and undertrays suffer from grounding, while aluminium panels need careful assessment for previous repair. Brake discs, pads and handbrake mechanisms can deteriorate on cars stored for long periods.
Interior, ownership costs and choosing well
Carbon-effect fabric, leather and soft-touch finishes can wear or become sticky. Test the infotainment unit, climate control, windows, seats, alarm, central locking and instruments. Inspect seat bolsters, headlining, door cards and the rear cabin, and verify that tools, tyre equipment, books, keys and coded security items remain present.
A cheap GranSport with deferred clutch, suspension and cosmetic work is rarely cheap to restore. Look for regular specialist invoices, a recent diagnostic report, strong hot and cold behaviour and a clean structure. The best cars combine a measured clutch, healthy Cambiocorsa hydraulics, sorted dampers and bushes, complete trim and evidence of frequent use rather than long neglect.
Sources and further reading
- Maserati Classiche: GranSport and GranSport Spyder
- Maserati: period GranSport brochure
- PistonHeads: Maserati GranSport used buying guide
- Maserati Club UK: marque and ownership resources
Continue the Maserati story
The GranSport was the most focused road development of Maserati’s first modern naturally aspirated V8 coupé. Explore the complete Maserati hub. Compare the twin-turbo 3200 GT. Explore the earlier Ghibli II.
Frequently asked questions
What engine is in the Maserati GranSport?
It uses a 4,244cc naturally aspirated dry-sump V8 producing 400hp.
Is Cambiocorsa an automatic gearbox?
It is a six-speed automated manual with a conventional clutch operated by electro-hydraulic controls and steering-wheel paddles.
How many GranSports were made?
Maserati records 2,640 coupés and 473 GranSport Spyders.
What is the GranSport MC Victory?
It is a limited version celebrating Maserati’s FIA GT success, with racing-influenced seats, carbon trim and distinctive detailing.
What should be checked before buying?
Obtain a clutch-wear reading and inspect the shift hydraulics, V8 service history, Skyhook dampers, suspension, corrosion and interior trim.
